KwiKool KIB6023-2 – 60,000 BTU/h – 5 ton air-cooled – 230v 3Phase

The KwiKool KIB6023-2 replaces the KIB6023 and has a wide operating range from 60ºF-110ºF

• 60,000 BTU/H – 5 Ton capacity air-cooled
• ETL and CETL listed to UL and CSA standards
• Includes KwiKool’s Exclusive I/O Integral Condenser where both inlet and outlets are ductable, without costly and bulky add-on kits
• THD Twin Hyper Drive Technology produces high volume of air without belts and eliminates all of the maintenance associated with belts
• Multi-function microprocessor control with a large, easy-to-read LCD display
• Easy-touch control pads make changing system settings a snap
• Self-Diagnostics that include audible alarm and LCD visual display readout for system fault conditions
• Input/Output Alarm Contacts for connection to building systems
• Internal high lift condensate pumps and a 5- gallon reservoir tank for total condensate flexibility
• Condensate overflow protection
• Three fan speeds
• Auto speed- automatically sets fan speed based on heat load demand (not available on single speed models)
• 27.312W”x50D”x53.5H”
• Weight – 523 lbs.
